vertical wheelchair lifts
If you have difficulty using stairs, or use a wheelchair or mobility scooter, then a residential vertical lift is a great way to ensure that you can always safely and conveniently enter and exit your home. All of our porch lifts are designed to be completely resistant to the harshest weather conditions and are an affordable alternative to residential elevators.
wheelchair lifts
|
MaxPlatform Height |
8000mm |
|
|
Min Platform height |
80mm |
|
|
Configuration |
Open through or front and side entrances |
|
|
Speed |
60mm/s |
|
|
Load capacity |
250KG~350KG |
|
|
Control voltage |
24V/DC |
|
|
Power Output |
1.5KW |
|
|
Power Input |
220V/50HZ/25A (or customized for local power supply) |
|
|
Drive System |
Hydraulic |
|
|
Control Mode |
Inching Switch or Automatic |
|
|
Drive Control |
Self-resetting system |
|
|
Overload |
Protection Over current relay |
|
|
Material of Platform |
Checkered slip-proof aluminum alloy |
|
|
Painting |
Plastic electrostatic spraying |
|
|
Guard panel & drivecabinet (framework) |
Aluminum Alloy / 304 stainless steel
|
|
|
Operation Panel |
Polished aluminum Alloy |
|
|
Safety Wane WorkingRange |
75° |
|
|
Working Condition |
Both indoors and outdoors |
|
|
Working temperature |
From -10°~60°C |
|
|
Installation
|
Non-pit installation, directly fixed to concrete floor (the concrete floor below the platform shall not be lower than the ground) |
|
|
Control Device |
Calling box (installed on the wall nearby) and remote controller(Extra optional) |
|
|
Emergency Stop
|
The lifting and lowering process can be stopped immediately by pressing the emergency button |
|
|
Safety device |
Safety Interlock |
Lock the platform when it is out of control |
|
SafetySensor |
The operation must be stopped immediately thesafety edge meets obstacles during operation. |
|
|
Emergencylowering |
The platform can be lowered by opening hydraulic valve manually or rolling screw rod. |
|
|
Auto-flap |
Turn up after lifting |
|
